45,000.00 / 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Volset |
| Driven Type | Electric |
| Surface Finishing | Polished |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Shape
Rectangle
Color
Siemens Grey
Cooling Type
Air Cooled
Operating Type
Automatic
Speciality
Easy To Use, High Efficiency, Reliable
Usage
Industrial Use
Certification
ISO9001:2015
Packaging Type
Carton Box
Standard
IS-2026
Mounting Type
Ground Mounted
Warranty
2 Year
Country of Origin
India
Type
Three Phase Isolation Transformer
Material
Copper
Voltage
220 V
Finishing
Coated
Power
10 KW
Standard Ratings
1 KVA - 600 KVA
Transformer Type
Aircooled / Oil Cooled for Indoor Application
Transformer Ratio
1 : 1 or Step Up or Step Down
Primary Voltage
415 Votls or Multitapping as per Requirements
Secondary Voltage
415 Votls or Multitapping as per Requirements
Connection
Delta-star, Star-star
Regulation
2 - 4 %
Di Electric Strength
Withstands 2500v for 1 Minute
Dc Galvanic Isolation
> 1000 Mega Ohms
Operating Power Factor
0.75 Lagging to 0.75 Leading
Movement
On Four Wheels
Indications
R/Y/B Phase
Frequency
50 Hz
Connection Type
Delta/star
Number of Phase
Three Phase
Power Rating
5kva -600kva
Winding Material
Copper,Mild Steel
Insulation Class
F Class
Winding Turns
Step Down
Voltage Ratio
415V - 200V
The main function of an Ultra Isolation transformer is supply of the output which is free from all surges/spikes.An Isolation transformer contains two windings:Primary and Secondary winding,that are separated from each other.Since the output is totally isolated from the input,any short circuit or faults on the primary side are not reflected on the secondary,thus avoiding damage to the sensitive electrical equipment. The supply of the output is free from all surges/spikes and so called electrical noise,which predominantly is present on the input side. for more info
