2.50 Lac / 1 piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Volset |
| Color | Grey |
| Automatic Grade | Automatic |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Application
Industrial Use
Frequency
50hz
Cooling System
Air Cooling
Country of Origin
India
Warrenty
1year
Standard Ratings
6-75 KVA
Type of Cooling
Aircooled / Oil cooled for indoor application
Servo Motor Drive
A.C. Synchronous Stepper Motor
Input Voltage Range
340-480 V / 295 -460 V / 270 - 460V / 240 - 460 V
Nominal Output Voltage
415 V ± 1%(380 V,400 V) or as per requirement
Voltage Correction Speed
>70 Volts/Sec (Ph-Ph) Air Cooled Only
Input Frequency
47 - 53 Hz
Output Voltage Regulation
± 1% of The Set Output Voltage
| TECHNICAL SPECIFICATION | THREE PHASE |
| Standard Ratings | 6-75 KVA |
| Type of Cooling | Aircooled / Oil cooled for indoor application |
| Model | Digital |
| Servo Motor Drive | A.C. Synchronous Stepper Motor |
| Input Voltage Range | 340-480 V / 295 -460 V / 270 - 460V / 240 - 460 V |
| Nominal Output Voltage | 415 V ± 1%(380 V,400 V) or as per requirement |
| Voltage Correction Speed | >70 Volts/Sec (Ph-Ph) Air Cooled Only |
| Single Phasing Prevention | Available |
| Input Frequency | 47 - 53 Hz |
| Output Voltage Regulation | ± 1% of The Set Output Voltage |
| Waveform Distortion | Nil |
| Effect of Load PF on Output Voltage | Nil |
| Efficiency | >98% |
| Output Electronic Under/Over Voltage Protection | Through Contactor at Output |
| Short Circuit Protection | MCB/MCCB at the Input |
| Front Panel Display indication | Digital Display » LED Indicator » Start /Stop » Menu » Auto/Manual Switch |
| Transformer | Aircooled / Oil cooled for indoor application |
|
Ratio |
1 : 1 or Step-up or Step-down (as per equipment) |
| Connections | Delta-Star, Star-Star |
| Regulation | 2 - 4 % |
| DI electric Strength | Withstands 2500V for 1 minute |
| DC Galvanic Isolation | > 1000 Mega Ohms |
| Operating Power Factor | 0.75 lagging to 0.75 leading |
| Movement | On double roller six wheels |
| Optional Accessories | » Ammeter With CT » Bye Pass Switch,Phase Reversal Protection » Transformer Oil In Case of Oil Cooled,Outdoor Design In Case of Oil Cooled |
